Input power in watts |
1000 |
1000 |
Propulsive power in watts |
480 |
480 |
Comparable petrol outboards (propulsive power) |
3 HP |
3 HP |
Comparable petrol outboards (thrust) |
4 HP |
4 HP |
Maximum overall efficiency in % |
48 |
48 |
Static thrust in lbs* |
68 |
68 |
Integrated battery |
530 Wh Li-Ion |
915 Wh Li-Ion |
Nominal voltage |
29.6 |
29.6 |
Final charging voltage |
33.6 |
33.6 |
Total weight in kg |
14.4(S) / 15.0(L) |
14.9(CS) / 15.5 (CL) |
Motor weight without battery in kg |
8.9(S) / 9.5(L) |
8.9(CS) / 9.5(CL) |
Weight of integrated battery |
5.5 |
6.0 |
Shaft length in cm |
62.5(S) / 75(L) |
62.5(CS) / 75(CL) |
Standard propeller v = speed in km/h at p = power in watts |
v9/p790 |
v9/p790 |
Alternative propeller options |
|
|
Maximum propeller speed in rpm |
1,200 |
1,200 |
Control |
Tiller |
Tiller |
Steering |
360° lockable |
360° lockable |
Tilting device |
Manual with grounding protection |
Manual with grounding protection |
Tilt angle |
70° |
70° |
Trim device |
Manual, 4-step |
Manual, 4-step |
Integrated on-board computer |
Yes |
Yes |
Stepless forward/reverse drive |
Yes |
Yes |
